Supercritical CO2 Extraction Machine
BIT – The Beauty of Modern Industry
Supercritical CO2 Extraction Machine
BIT’s CO2 Extraction Equipment is available in a range of sizes and capacities to meet the processing requirements of different applications: Includes small-scale operations and research(home), medium-scale processing, and industry-grade CO2 extraction machines; with capacities ranging from 4 oz up to 3000 lb for production of essential oil/CBD oil and other extracts.
- Extraction pressure: 35MPa up to 105MPa;
- Tabletop CO2 Extractor: 100 – 200 mL;
- Small CO2 Extraction Machine: 0.5 – 5 L;
- CBD Oil CO2 Extraction Machine/CO2 Essential Oil Extraction Equipment: 10 L up to 9000 L.
BIT’s Industrial CO2 Extraction Machine Standard Parameter Table
| Models | Capacity liter | Extraction Capacity (24 hours/kg) | Work Pressure (MPa) | Extraction Vessels Number | Separation Vessels Number |
| P-10D | 20(10L×2) | 27.5 | 50 | 2 | 2 |
| P-30D | 60(30L×2) | 82.5 | 45 | 2 | 2 |
| P-50D | 100(50L×2) | 137.5 | 40 | 2 | 2 |
| P-30F | 120(30L×4) | 165 | 40 | 4 | 3 |
| P-50F | 200(50L×4) | 275 | 40 | 4 | 2 |
| P-50S | 300(50L×6) | 412.5 | 40 | 6 | 3 |
| I-150D | 300(150L×2) | 412.5 | 40 | 2 | 3 |
| I-150T | 450(150L×3) | 787.5 | 40 | 3 | 3 |
| I-200T | 600(200L×3) | 1050 | 35 | 3 | 3 |
| I-300T | 900(300L×3) | 1575 | 35 | 3 | 3 |
| I-500D | 1000(500L×2) | 1375 | 35 | 2 | 3 |
| I-500T | 1500(500L×3) | 2625 | 35 | 3 | 3 |
| I-600T | 1800(600L×3) | 3150 | 35 | 3 | 3 |
| R-1000D | 2000(1000L×2) | 2750 | 35 | 2 | 3 |
| R-1500D | 3000(1500L×2) | 4125 | 35 | 2 | 3 |
| R-1000T | 3000(1000L×3) | 5250 | 35 | 3 | 3 |
| R-2000D | 4000(2000L×2) | 5500 | 35 | 2 | 3 |
| R-1500T | 4500(1500L×3) | 7875 | 35 | 3 | 3 |
| R-3000D | 6000(3000L×2) | 8250 | 35 | 2 | 3 |
| R-2000T | 6000(2000L×3) | 10500 | 35 | 3 | 3 |
| R-3000T | 9000(3000L×3) | 15750 | 35 | 3 | 3 |
